MCI 61303 Motorized Coaxial Switch 3 Port 1-5/8 ” Eia W: 15lbs SD: 15x 15

Description

Upgrade your setup with the MCI 61303 Motorized Coaxial Switch 3 Port 1-5/8 ” Eia W: 15lbs SD: 15x 15, a RF component made for broadcast engineers building or upgrading a transmission site who expect efficient, low-loss RF performance.

Key Features

• <p>MEGA RF Solutions 3 &amp
• 3 PORT 1-5/8 ” EIA Connector Motorized Coaxial Switches
• MCI Coaxial Transfer Switches, a product of Mega Industries, are designed primarily for application in TV, AM, FM, UHF and other broadcast related areas
• As four-port transfer switches, they will switch two signal sources between loads
• Since they can also be used as SPDT switches, complex-switching matrices can easily be assembled.</p&gt
• <p>A unique feature of these switches is the coplanar port configuration
• In most installations, this permits neater, more compact layouts and requires fewer elbows

Specifications & Details

These switches are usually one-half to one-third the weight and occupy between one-half and one-sixth the volume of other commercially available switches.</p> <p>Independent interlock/logic circuits are available for transmitter blanking, logic input or position indication on all but the Type N model. These circuits are isolated from the switch control circuits and from ground. Internal interlocks are also included to remove the drive power at the end of the switching cycle to prevent inadvertent damage to the drive motor.</p> <p>Action is accomplished by a standard high torque gear motor and is bi-directional to positive stops. In the event of loss of control power, these switches can be operated manually.</p>

Part number / SKU: MCI61303  ·  Manufacturer: MCI
