DEVA Broadcast DB7007 FM RE-Broadcast Receiver

Description

When dependable program delivery matters, stations moving audio and video between studio, transmitter and remote sites turn to gear like the DEVA Broadcast DB7007 FM RE-Broadcast Receiver — a dependable link solution from DEVA.

Key Features

• <p>Thanks to the built-in monitoring system, upon audio loss at the inputs, DB7007 will not only notify the maintenance staff, butwill also automatically switch to the second back-up RF Station
• In case a fail of the second station is detected, DB7007 will shift to the incorporated IP Stream, MP3/AAC back-up audio source player
• It is essential that the back-up sources priority is user-defined
• Depending on your preferences,several types of alarm notifications are utilized – E-mail, SNMP and SMS (via the optional GSM modem).</p&gt
• The RF (IF) signal is digitized as soon as it enters the device and all signal processing is then made through DSP algorithms, thus guaranteeing measurement reproducibility over time
• The IF bandwidth filters guarantees unprecedented signal selectivity, while the difficult adjacent-channel problem will be completely solved
• DEVA advanced DB7007 will measure all important parameters of the FM transmission.</p&gt

Specifications & Details

<p>Additionally, the RDS information contained in the processed MPX signal is easily visualized and represented as RDS/RBDS Data and detailed RDS/RBDS Statistics. The utilized Band Analyzer function presents an overview of all available FM signals, plus the RF signal strength. Scans can be performed within any section of the FM band in 4 different frequency steps. The consequently generated spectrum diagram visualizes the relation RF Level vs. Frequency.</p>

Part number / SKU: DEVDB7007  ·  Manufacturer: DEVA
