Connector 2 x 1/4″ TS unbalanced
-Input Impedances Switchable:
-≥ 10kΩ mic/line
-1MΩ guitar
-Nominal Input Level -10 dBV
-Maximum Input Level +6 dBV
-Headroom 16 dB
-Connector 1/8″ (3.5 mm) stereo mini
-Nominal Output Level -16 dBV
-Maximum Output Level 0 dBV
-Frequency Response 20 Hz to 20 kHz +1/-3 dB-
-Distortion < 0.05%
-Signal-to-Noise Ratio > 81 dB
-Power Requirements 4 x AA batteries (alkaline or NiMH)
-TASCAM PS-P520 AC adapter (sold separately)
-Battery Life (approx.) 8 hrs alkaline, 9 hrs NiMH (using line input/recording)
-8.5 hrs alkaline, 9.5 NiMH (using headphone/playback)
-Power Consumption 1W maximum
-Operating Temperature Range 41 to 95°F (5 to 35°C)

http://www.tascam.com/content/downloads/products/786/e_dp-006_om_va_2.pdf
