Audio Delay User adjustable 1 sample to 500 ms
-Graphic EQ 31 to 16 kHz, 1/3 octave
-Digital I/O AES Sample Rate Converter range: 8 to 200 kHz
-External World Clock In range: 48 kHz ±7 Hz (internal systems), ±3 Hz with stageboxes
-Word Clock Out jitter: ±7 ns
-Analogue Out for 0 dBfs: +21.5 dBu
-Converter resolution: 24 bit
-DSP resolution: 40 bit floating point
-Latency Mic In to Line Out: -Analogue In to AES Out: -AES In to Line Out: -AES In to AES Out; -Stagebox Mic In to Stagebox: -Input Level Mic Input: +22 dBu max
-Line Input: +22 dBu max
-Output Level Mix Output: +21.5 dBu max
-Headphones at 150 Ω 300 mW (recommended impedance 32 to 200 Ω)
