-Effective Picture Elements 1920 (H) x 1080 (V)
-Gain -3, 0, 3, 6, 9, 12, 15, 18 dB, AGC
-Horizontal Resolution 1,000 TV lines or more (1920 x 1080i mode)
-Imaging Device 3-chip 1/3″-type Exmor Full HD CMOS
-Minimum Illumination 0.12lx (typical, 1920 x 1080/59.94i mode, F1.6, +18 dB gain, with 16 frame accumulation, Gamma off, 100% video level)
-0.02lx (typical, 1920 x 1080/59.94i mode, F1.6, +18 dB gain, with 16 frame accumulation, Gamma off, 50% video level)
-Optical System F1.6 prism system
-S/N Ratio 60 dB (Y) (typical)
-Sensitivity (2000 lx, 89.9% reflectance) F9 (typical) (1920 x 1080/59.94i mode)
-F10 (typical) (1920 x 1080/50i mode)
-Shutter Speed (Time) 1/32 to 1/2000 sec.
-Operating Temperature 32°F to 104°F (0°C to 40°C)
-Power Consumption approx. 19.9W (while recording with LCD Off, EVF On when the external device connector is not used.)
-approx. 20.8W (while recording with LCD On, EVF On when the external device connector is used.)
-Power Requirements DC 14.4V (battery pack)
-DC 19.5V (AC adaptor)
-Audio Input XLR type 3-pin (2), female, LINE/MIC/MIC+48V switchable; – MIC: -50 dBu/3 kΩ; – LINE: +4 dBu/10 kΩ; (Reference input level 0 dBu=0.775Vrms)
-Audio Output Stereo minijack (Ø 3.5 mm); -10 dBu (Under 47 kΩ load, reference level)
-DC Input DC jack (1)
-DC Output No
-EXT 50-pin No
-Genlock Input BNC type (1), switchable with VIDEO OUT connector; 1.0 Vp-p, 75 Ω
-HDMI Output HDMI connector – Type A (1)
-Headphone Output Stereo minijack (Ø 3.5 mm) -19 dBu (Reference level output under 16 Ω load)
-MIC Omnidirectional stereo electret condenser microphone
-Remote Stereo mini-mini jack 2.5mm (1)
-SDI Output BNC type (1), switchable with 3G SDI/HD-SDI/SD-SDI
-SMPTE292M/259M/424M/425M standards
-Speaker Output Monaural, 50 mW
-Timecode Input BNC type (1), switchable with TC OUT connector; SMPTE 12M-2-2008; 0.5 V to 18 Vp-p, 3.3 kΩ
-Timecode Output BNC type (1), switchable with TC IN connector SMPTE 12M-2-2008 2.0 Vp-p, 50 Ω
-USB Mass storage: USB2.0 mini-B (1); Host: Type A USB3.0 (1) supported by future software upgrade; Host: Type-A USB2.0 (1) to use with supplied wireless LAN module
-Video Output BNC type (1), HD-Y/HDSYNC/composite signal, 1.0Vp-p, 75Ω
-switchable with GENLOCK IN connector
-i.LINK No
-Filter Diameter M 82 mm (3 1/4 in.), pitch 0.75 mm
-Focal Length 3.7 mm to 92.5 mm (5/32 to 3 3/4 in.) (equivalent to 26 mm to 650 mm (1 1/16 to 25 5/8 in.) on a 35 mm lens)
-Focus AF / MF selectable.
-Iris F1.6-3.2; F1.6 to F11 and C (close); Auto/manual switchable
-Lens Mount fixed lens
-Zoom System 25x optical zoom
