-Built-in Optical Filters ND Filter (Optical) 1: Clear, 2: 1/4 ND, 3: 1/16ND 4: 1/64 ND
-CC Filter (Electrical) A: 3200K, B: 4300K, C: 5600K, D: 6300K
-Horizontal Resolution more than 1000 TV Lines
-Imaging Device 3-chip 2/3 type Full HD CCD, PowerHAD FX
-Minimum Illumination 0.016 lux (F1.4, +42dB, 16-frame accumulation)
-Optical System F1.4 prism system
-S/N Ratio 60 dB (NS On)
-Sensitivity (2000 lx, 89.9% reflectance) F11 (typical) @ 59.94i
-F12 (typical) @ 50i
-Operating Temperature 23°F to 104°F (-5°C to 40°C)
-Power Consumption approx. 37W (while XAVC recording with LCD On and CBK-VF02 viewfinder)
-Audio Input 3G / HD / SD-SDI Pool Feed Input
-Audio Output XLR 5-pin x1
-Composite Output BNC x1
-DC Output 4-pin, 11 to 17 V DC, 1.8 A
-Genlock Input BNC x1
-HDMI Output HDMI (Type A) x1
-Headphone Output 3.5 mm Stereo mini jack x1
-Lens Remote 12-pin x1
-MIC XLR-type, 5-pin, female: -70 to -30 dBu
-Remote 8-pin x1
-SDI Output BNC x2
-Timecode Input BNC x1
-Timecode Output BNC x1
-USB USB 2.0 ( type B), USB 3.0 (type A)
-VF 20-pin HDVF type and 26-pin for CBK-VF02
-Wireless Receiver IN Slot for receiver
