-Effective Picture Elements 1920 x 1080 (H x V)-
-Effective Pixels 1920 x 1080 (H x V)
-Gain Selection -3, 0, 3, 6, 9, 12 dB
-Horizontal Resolution 1,000 TV lines or higher
-Optical System F1.4 prism system
-S/N Ratio Typical 60dB*2 (1080/59.94i)
-Sensitivity F12 (59.94 Hz), F13 (50 Hz)
-Operating Temperature 14°F to +113°F
-Power Consumption Approx.18W (Camera body only)
-Approx. 21W (Camera body with supplied viewfinder)
-Power Requirements CCU: DC48V, 2.8A (max.)
-Ext.DC In: DC12V, 5.4A (max.)
-Storage Temperature -4°F to +140°F
-CCU Optical Fiber (x1), CCFN cable or Single Mode Fiber cable (LC type)
-Intercom XLR type, 5-pin, female (1)
-Prompter BNC (x1); Gen-Lock In or Prompter Out
-Remote 8pin (x1)
-Viewfinder 20-pin (1), for HDVF only
-DC In XLR-type 4-pin (x1), DC 10.5 V to 17 V
-DC Out 4-pin (1), DC 10.5 V to 17 V, 1.5 A (max.)
-Test Out TEST Out (Analog output with/without characters), or HD/SD Sync Out
-USB USB 2.0 (x1)
