-Built-in-Filters ND)1: CLEAR, 2: 1/4ND, 3: 1/16ND 4: 1/16ND, 5: 1/64ND
-Dynamic Range 600%
-Effective Picture Elements 1920 x 1080 (H x V)
-Gain Selection -6,-3,0,+3,+6,+9,+12 (standard)
-Horizontal Resolution 1000tvl
-Lens Mount B4
-Modulation Depth Y: 50% at 27.5 MHz (800 TV lines with typical lens)
-Optical System F1.4 prism system
-Pickup Device 3-chip 2/3-inch type CCD (IT)
-S/N Ratio 60db(Typical) 64db with NS
-Sensitivity F10 (1080i/59.94 mode), F11 (1080i/50 mode) (at 2000 lx, 3200 K, 89.9% reflectance)
-Format 1080i and 720p standard
-Operating Temperature -20°C to +45°C (-4°F to +113°F)
-Power Requirements 240 V AC, 1.4 A (max.), 180 V DC, 1.0 A (max.), 12 V DC, 7 A (max.)
-Storage Temperature -20°C to +60°C (-4°F to +140°F)
-Weight 4.5 kg (9 lb 15 oz)
-Audio Input (Ch1, Ch2) XLR 3-pin (x2) (female)
-DC IN XLR 4-pin (x1)
-Genlock/Return IN BNC (x1), 1 Vp-p, 75 Ω
-Return Control 6-pin (x1)
-CCU Optical / electrical multi-connector (x1)
-Crane 12-pin (x1)
-Intercom Intercom 1 / Intercom 2 XLR 5-pin (x2) (female)
-Lens 12-pin (x1)
-Prompter Prompter output / Genlock input BNC (x1), 1 Vp-p, 75 Ω
-Prompter output / Return input BNC (x1), 1 Vp-p, 75 Ω
-Remote 8-pin (x1)
-Tracker 10-pin (x1)
-Audio / Headphone Output(s) Mic input XLR 3-pin (x1) (female)
-Audio In (Ch1, Ch2) XLR 3-pin (x2) (female)
-DC In XLR 4-pin (x1)
-DC Out mini type 4-pin (x1) (DC 10.5 V to 17V, max. 0.5 A)
-2-pin (x1) (DC 10.5 V to 17V, max. 2.5 A)
-Earphone Stereo mini-jack 3-pin (x1)
-HD-SDI Out (Dual Link) SDI 1 BNC (x1) (3G / HD-SDI output)
-SDI 2 BNC (x1) (HD-SDI input / output)
-SDI monitor output BNC (x1) (HD-SDI / SD-SDI)
-Memory Stick Type A 4-pin (x1)
-Test Out BNC (x1), 1 Vp-p, 75 Ω
