-Operating Temperature 14°F to +113°F -Power Consumption 17W -Power Requirements CCU: DC48V, 1.7A (max.) -Ext.DC In: DC12V, 3.6A (max.) -Storage Temperature -4°F to +140°F -CCU Optical Fiber (x1), for Single Mode Fiber Cable -Lens 12-pin (x1) -Remote 8pin (x1) RJ-45 (x1), Ether 10BASE-T, 100BASE-TX -DC In XLR-type 4-pin (x1), DC 10.5 V to 17 V -DC Out DC 10.5 V to 17 V, 1.5 A (max.) via D-Sub 9pin -MIC In -60dBu to -20dBu, Balance, . . .

Read More

-Operating Temperature 14°F to +113°F
-Power Consumption 17W
-Power Requirements CCU: DC48V, 1.7A (max.)
-Ext.DC In: DC12V, 3.6A (max.)
-Storage Temperature -4°F to +140°F
-CCU Optical Fiber (x1), for Single Mode Fiber Cable
-Lens 12-pin (x1)
-Remote 8pin (x1) RJ-45 (x1), Ether 10BASE-T, 100BASE-TX
-DC In XLR-type 4-pin (x1), DC 10.5 V to 17 V
-DC Out DC 10.5 V to 17 V, 1.5 A (max.) via D-Sub 9pin
-MIC In -60dBu to -20dBu, Balance, via D-Sub 9pin, female (x1)
-SDI In BNC (x2) HD-SDI or SD-SDI selectable
-USB USB 2.0 (x1)
