Built-in Optical Filters 1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND
-Effective Picture Elements 1920 (H) x 1080 (V)
-Gain -3, 0, 3, 6, 9, 12, 18, 24, 30, 36, 42 dB
-Horizontal Resolution 1,000 TV lines or higher (1920 x 1080i mode)
-Imaging Device 3-chip 2/3-type “Exmor” Full HD CMOS
-Minimum Illumination 0.013 lx (F1.4, +42 dB, 16-frame accumulation)
-Optical System F1.4 prism system
-S/N Ratio 62 dB (Y) (Noise Suppression On)
-Sensitivity (2000 lx, 89.9% reflectance) F12 (typical) (1920 x 1080/59.94i mode)
-F13 (typical) (1920 x 1080/50i mode)
-Shutter Speed (Time) 59.94i/p, 50i/p: 1/60 sec. to 1/2000 sec. + ECS *3 29.97p: 1/40 sec. to 1/2000 sec. + ECS *3 25p: 1/33 sec. to 1/2000 sec. + ECS *3 -23.94p: 1/32 sec. to 1/2000 sec. + ECS *3
-Slow & Quick Motion Function 720p: Frame rate selectable from 1 fps to 60 fps
-1080p: Frame rate selectable from 1 fps to 60 fps
-Slow Shutter 2, 3, 4, 5, 6, 7, 8, 16-frame accumulation
-White Balance Preset (3200K), Memory A, Memory B/ATW
-Operating Temperature 32° F to 104° F
-Power Consumption Approx. 22 W (while XAVC recording, color LCD on)
-Approx. 24 W (while XAVC recording, CBKVF02 viewfinder and color LCD on)
-Power Requirements DC 12 V (11 V to 17.0 V)
-Audio Input CH1/CH2: XLR-type 3-pin (female) (x2), Line/Mic/Mic/+48V selectable LINE: +4, 0, -3 dBu AES/EBU: AES3 compliant MIC: -70 dBu to -30 dBu
-Audio Output XLR-type 5-pin, male, +4/0/-3 dBu (balanced)
-DC Input XLR-type 4-pin, male, 11 V to 17 V DC
-DC Output Round type 4-pin, 11 V to 17 V DC, 1.8 A maximum rated current
-Genlock Input BNC (x1), 1.0 Vp-p, 75 Ω, unbalanced
-HDMI Output A type, 19-pin (x1)
-MIC XLR-type 5-pin, female: -70 dBu to -30 dBu
-Remote 8-pin
