-Effective Picture Elements 17:9 4096 (H) x 2160 (V); 16:9 3840 (H) x 2160 (V)
-Gain -3, 0, 3, 6, 9, 12, 18 dB, AGC
-Imaging Device Super35 type Single-chip Exmor CMOS
-Minimum Illumination 0.7 lx (+18dB,23.98P,Shutter OFF,ND Clear, F1.4)
-S/N Ratio 57 dB (Y) (typical)
-Sensitivity (2000 lx, 89.9% reflectance) Video Gamma: T14 (3840 x 2160/23.98P mode 3200K)
-Shutter Speed (Time) 1/3 sec to 1/9,000 sec
-Audio Input XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable Mic Reference: -40, -50, -60dBu
-DC Input DC jack
-HDMI Output Type A (x1)
-Headphone Output Stereo mini jack (x1) -16dBu 16Ω
-Remote Stereo mini-mini jack (Φ2.5 mm)
-SDI Output BNC(x2), switchable with 3G-SDI/HD-SDI SMTPE292M/424M/425M
-Speaker Output Monaural
-USB USB device, mini-B (x1)
-Filter Diameter 95mm
-Focal Length 18mm to 110mm
-Focus Internal
-Iris Seven blades (circular aperture) F/4
-Lens Mount Sony E-mount
-Zoom System Both manual and powered
-Operating Temperature 32°F to 104°F (0°C to 40°C )
-Power Consumption Approx. 19W (while recording XAVC-I QFHD 59.94P, SELP18110G Lens, Viewfinder ON, not using external device)
-Power Requirements DC 16.5V (battery pack)
-DC 12.0V (AC adaptor)
