-Horizontal Resolution 2000 TV lines (at center) in 4K, 5% or higher modulation -Pickup Device 3-chip 2/3-inch type CMOS -Sensitivity F8.0 (2000 lx, 89.9% reflection) -Spectrum System F1.4 prism -Operating Temperature -4°F to +113°F -Power Requirements AC 240 V, 1.4 A (max.), DC 180 V, 1.0 A (max.), DC 12 V, 7 A (max.) -Storage Temperature -4°F to +140°F -DC IN XLR-type 4-pin (x1), DC 10.5 V to 17 V -Genlock/Return IN 1 Vp-p, 75 Ω - . . .

Read More

-Horizontal Resolution 2000 TV lines (at center) in 4K, 5% or higher modulation
-Pickup Device 3-chip 2/3-inch type CMOS
-Sensitivity F8.0 (2000 lx, 89.9% reflection)
-Spectrum System F1.4 prism
-Operating Temperature -4°F to +113°F
-Power Requirements AC 240 V, 1.4 A (max.), DC 180 V, 1.0 A (max.), DC 12 V, 7 A (max.)
-Storage Temperature -4°F to +140°F
-DC IN XLR-type 4-pin (x1), DC 10.5 V to 17 V
-Genlock/Return IN 1 Vp-p, 75 Ω
-Return Control 6-pin (x1)
-Crane 12-pin (x1)
-Intercom XLR-type 5-pin, female (1 each)
-Prompter BNC (x1), 1 Vp-p, 75 Ω
-BNC (x1), 1 Vp-p, 75 Ω
-Remote 8-pin (x1)
-Tracker 10-pin (x1)
-Viewfinder 20-pin (x1)
-DC In XLR-type 4-pin (x1), DC 10.5 V to 17 V
-DC Out 4-pin (x1), DC 10.5 V to 17 V, 0.5 A (max.) 2-pin (x1), DC 10.5 V to 17 V, 2.5 A (max.) (Limitations may apply, depending on the load and input conditions.)
-Earphone Stereo mini jack (x1)
-Lens 12-pin (x1)
-MIC In XLR-type 3-pin, female (x 1)
-SDI In BNC (1 each)
-Test Out BNC (x1)
-USB USB 2.0, Type A, 4-pin (x1)
