Built-in Optical Filters 1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND-
-Effective Picture Elements 3840 (H) x 2160 (V)
-Gain -9, -6, -3, 0, 3, 6, 9, 12, 18, 24, 30, 36, 42 dB(TBD)
-Imaging Device 2/3-type “Exmor R” 4K CMOS
-Minimum Illumination 0.019 lx (F1.4, +42 dB, 16-frame accumulation)
-S/N Ratio 61 dB typical (typical, 1920×1080/59.94i mode, Noise Suppression On)
-Sensitivity (2000 lx, 89.9% reflectance) F10 (typical) (1920 x 1080/59.94i mode or 3840 x 2160/59.94p mode)
-F11 (typical) (1920 x 1080/50i mode or 3840 x 2160/50p mode)
-Slow & Quick Motion Function 1080p: Frame rate selectable from 1fps to 60 fps
-Slow Shutter 2, 3, 4, 5, 6, 7, 8, 16-frame accumulation
-White Balance Preset (3200K), Memory A, Memory B/ATW
-Battery Operating Time Approx. 160 min with BP-FLX75
-Operating Temperature 32° F to 104° F
-Power Consumption Approx. 24 W (while XAVC recording, color LCD on)
-Approx. 26 W (CBK-VF02 viewfinder, lens, microphone, while XAVC recording, color LCD on)
-Power Requirements DC 12 V (11 V to 17.0 V)
-Audio Input CH1/CH2: XLR-type 3-pin (female) (x2), Line/Mic/Mic/+48V selectable LINE: +4, 0, -3 dBu AES/EBU: AES3 compliant MIC: -70 dBu to -30 dBu
-Audio Output XLR-type 5-pin, male, +4/0/-3 dBu (balanced)
-DC Input XLR-type 4-pin, male, 11 V to 17 V DC
-DC Output Round type 4-pin, 11 V to 17 V DC, 1.8 A maximum rated current
-Genlock Input BNC (x1), 1.0 Vp-p, 75 Ω, unbalanced
-HDMI Output A type, 19-pin (x1)
-Headphone Output Stereo mini jack (x1) -11 dBu reference level output, maximum monitor volume, 16 Ω load
-MIC XLR-type 5-pin, female: -70 dBu to -3 0 dBu
-Remote 8-pin
-SDI Input SMPTE ST292/ST259 standard compliant, 4-channel audio 1.5G
-Poolfeed Recording (upto 1080 59.94i)
-SDI Output Output 1/2/3/4: BNC (x4), 0.8 Vp-p,
-Speaker Output Monaural, 300 mW output
-Timecode Input BNC (x1), 0.5 V to 18 Vp-p, 10 kΩ
-Timecode Output BNC, 1.0 Vp-p, 75 Ω
-USB USB 3.0/2.0 4-pin (type A), USB2.0 4-pin (type B), USB2.0 4-pin (type-A)
-VF 20-pin IF for HDVF Series Viewfinder, and 26-pin IF for CBK-VF02, HDVF-L750
-Video Output BNC, SD analog composite/HD-Y selectable
-Wireless Receiver IN D-sub 15-pin Analog CH1: -40 dBu Digital CH1/CH2: -40 dBFS
