-Inputs:
4 Microphone inputs; 3 external dynamic MIC and one internal condenser MIC.
One line input for cassete, DAT or digital recorder

-MIC input level:
From -20 to -75 dBu.
Non clipping MIC preamplifier at any level

-Audio output:
Balanced audio output 0 dBu / 10 Kohms

-Hybrid Outputs:
2 outputs with internal Hybrid. One for phone line (POT) and one for cellular phone

-Headset outputs:
3 outputs for headsets. Z= 8 to 600 ohms
With separate amplifier with level control

-Frequency Response:
Flat 20-15.000 Hz plus an anti-pop filter with -6 dB @ 30 Hz and Low pass filter -3 dB @ 12 Khz

-THD Distortion:
Less than 0,4 % @ 1 Khz

-Noise:
70 dBA Signal/Noise ratio with -40 dBu MIC level

-Audio Compressor:
16 dB action with 2 LED indication.
10 ms attack time and 200 ms recovery

-Fast Limiter:
Peak limiter after compressor stage to avoid digital saturation of cellular phones.

-Electronic Technology:
Full use of advanced CMOS amplifiers with very low power consumption , for long battery duration

-Cellular connection:
Full wireless Bluetooth connection with 16 bits converter.
Red and Green indication of status
Backup of cellular link: RJ11 open cable to be connected to the Hands-free kit of the second cellular phone.
