AES Audio No
Audio Bits 24
Bus Expansion No
Color Dark Grey
Conversion 44.1 kHz 24-bits
Crosstalk < -80 dBu
Depth 15″ (381 mm)
Frequency Response within ±1dB from 50 Hz – 20 kHz at 20 dBu
Height 1.75″ (44.5 mm)
Input Impedance 22KΩ KΩ
Integrated Party-Line Interface Yes
Intuitive User Interface Yes
Keypanel Data Ports RS485 with dedicated transceivers for every port
Link Method N/A
Matrix PC Connection Ethernet, Serial, USB
Maximum Level 20 dBu
Memory Non-volatile Flash
Nominal Input/Output 5 kΩ
Nominal Level 8 dBu
Non-Destructive Download Yes
Output Impedance 600Ω
PC Port Yes
Port Capacity: Single Frame 32 keypanel ports, 2 party line ports with call signaling
Power Requirements 90-264VAC 50/60Hz
Rack Units 1
Redundant Controllers No
Redundant Power Supplies Yes
Relays 2
Remote Configuration Yes
Signal Type Balanced
Signal-to-Noise Ratio > 85 dB at 20 dBu (A-weighted)
Total Harmonic Distortion < 1 % at channel output with nominal input
Total Harmonic Distortion+Noise < 0.01 % at 20 dBu, 1 kHz (unweighted)
Trunking Yes
USB Port Yes
VOX on Input Yes
Weight 7 lbs (3.18 kg)
Width 16.37″ (415.8 mm)
