AES Audio No -Audio Bits 24 -Bus Expansion No -Color Dark Grey -Conversion 44.1 kHz 24-bits -Crosstalk < -80 dBu -Frequency Response within ±1dB from 50 Hz - 20 kHz at 20 dBu -Input Impedance 22KΩ KΩ -Integrated Party-Line Interface Yes -Intuitive User Interface Yes -Keypanel Data Ports RS485 with dedicated transceivers for every port -Link Method N/A -Matrix PC Connection Ethernet, Serial, USB -Maximum Level 20 dBu -Memory No . . .

Read More

AES Audio No
-Audio Bits 24
-Bus Expansion No
-Color Dark Grey
-Conversion 44.1 kHz 24-bits
-Crosstalk < -80 dBu
-Frequency Response within ±1dB from 50 Hz – 20 kHz at 20 dBu
-Input Impedance 22KΩ KΩ
-Integrated Party-Line Interface Yes
-Intuitive User Interface Yes
-Keypanel Data Ports RS485 with dedicated transceivers for every port
-Link Method N/A
-Matrix PC Connection Ethernet, Serial, USB
-Maximum Level 20 dBu
-Memory Non-volatile Flash
-Nominal Input/Output 5 kΩ
-Nominal Level 8 dBu
-Non-Destructive Download Yes
-Output Impedance 600Ω
-PC Port Yes
-Port Capacity: Single Frame 32 keypanel ports, 2 party line ports with call signaling
-Power Requirements 90-264VAC 50/60Hz
-Rack Units 1
-Redundant Controllers No
-Redundant Power Supplies Yes
-Relays 2
-Remote Configuration Yes
-Signal Type Balanced
-Signal-to-Noise Ratio > 85 dB at 20 dBu (A-weighted)
-Total Harmonic Distortion < 1 % at channel output with nominal input
-Total Harmonic Distortion+Noise < 0.01 % at 20 dBu, 1 kHz (unweighted)
-Trunking Yes
-USB Port Yes
-VOX on Input Yes

Read Less
