Connection: DB25 connector -Total # of Inputs: 16 -Input Impedance: 24kΩ -Nominal Input Level: +4dBu or -10dBu (solder link selectable) -Maximum Input Level: +24dBu -Connection: 75Ω unbalanced BNC -Total # of Outputs: 16 -Output Impedance: 50Ω -Nominal Output Level: +4dBu or -10dBu (selectable via solder links per output) -Maximum Output Level: +24dBu -Frequency Response: ±0.1 -dB 20Hz to 20kHz --3dB, 100kHz -Distortion: 0.005% . . .

Read More

Connection: DB25 connector
-Total # of Inputs: 16
-Input Impedance: 24kΩ
-Nominal Input Level: +4dBu or -10dBu (solder link selectable)
-Maximum Input Level: +24dBu
-Connection: 75Ω unbalanced BNC
-Total # of Outputs: 16
-Output Impedance: 50Ω
-Nominal Output Level: +4dBu or -10dBu (selectable via solder links per output)
-Maximum Output Level: +24dBu
-Frequency Response: ±0.1
-dB 20Hz to 20kHz
–3dB, 100kHz
-Distortion: 0.005%
-Noise: -90dB
-Crosstalk: below noise
-Number of Levels: dual independent matrix layers
-Control Level: no
-Partitioning: up to 8 partitions with independent level assignment
-Configuration: web browser via NK-IPS
-DashBoard Control System via NK-IPS
-Dimensions: 1RU, depth 6.4cm
-Power Consumption: 19W
-Power Supply: ±15 V DC
