-Input Impedance: Mic: 10K Ohms XLR balanced 1/4″: 20K Ohms unbalanced Bus Input: 10K Ohms unbalanced
-CMRR: >80 dB (Mic)
-THD: <.009%
-Max S/N ratio: 106 dB
-Phase Shift: <10 degrees, 20Hz to 20 kHz
-Output Impedance: 51 Ohms
-Output Level: +22 dBV max
-Phantom Power: +48 VDC
-Tone Control: 12 dB Treble/Bass cut
-Max Gain: Mic: 55 dB Line: 26 dB
-Outputs: XLR bal., RCA unbalanced Prefade out
-Input Connectors: 8: XLR, 8: 1/4″ (Line), 1: RCA (Bus input)
-Max Input Level: Mic: 0 dBV balanced Line: +6 dBV
-Power: 12 VAC (Rolls Model PS12)
