Input Connections 1 x XLR – Mic 1
1 x XLR – Mic 2
2 x RCA phono – Channel 2 (1 x L/R)
4 x RCA phono – Source Inputs (2 x L/R)
1 x 1/8″ TRS stereo – Channel 4
-Input Impedance XLR Mic: 600Ω balanced
XLR Line: 10kΩ balanced
RCA phono: 10kΩ unbalanced
1/8″ TRS: 10kΩ unbalanced
-Maximum Input Level Mic: -30 dB
-Line: +22 dB
-Phantom Power Yes, +48V
-Outputs
-Output Connections 4 x XLR
-Output Impedance 50Ω balanced
-Maximum Gain Mic: 60 dB
-Line: 30 dB
-Headphone Output 1 x 1/4″
-Internal Speakers Yes, 1 monitor speaker
