-Input Impedance:
-Mic: 10K Ohms XLR balanced
-Limiter Threshold: -5 dB to off, fully clockwise: No Limiting
-Setup Frequency: 1 kHz
-Slate Frequency: 20 Hz
-Output Attenuator: -30 dB
-Self Noise: -57 dB maximum, -90 dB typical
-Max Gain: +65 db
-S/N Ratio: 115 dB
-Frequency Response: 20 Hz – 30 kHz | +0, -3 dB
-Low Cut: 100 Hz
-Trim Range: 0 to + 38 dB
-Max Input: 0 dBV
-Current Draw: 45 mA with no Phantom Power or Signal.
-Phantom Power: +48 VDC
-Connectors: 4: Female XLR, 2: Male XLR, 3: 1/4″, 1: 1/8″ (3.5mm), 1 Center Negative power jack.
-Power: 12VDC / 200 mA
