Input Impedance: 20K Ohms balanced 10K Ohms unbalanced (1/4″)
-Weight: 7 lbs (3KG)
-Power: AC adapter 12 VAC (Rolls PS12)
-CMRR: 80 dB
-IMD (SMPTE): < .003%
-THD: < .003%
-Max S/N Ratio: 106 dB
-Tone controls: 12 dB cut/boost, 150Hz & 3KHz 3dB points
-(Monitor): 55 dB
-Max Gain: (Mains): 60 dB bal/unbal
-Outputs: 1/4″ main balanced +17 dB max 1/4″ monitor +17 dB max 1/4″ FX send 1/4″ TRS Stereo Headphone
-Phantom Power: 36 Volts DC
-Input Connectors: XLR and 1/4″
-Phase Shift: < 10 deg. 20 Hz – 20 kHz
-Max Input Level: +10 dBV XLR +10 dBV 1/4″
-Output Impedance: 50 OhmsTRS Balanced
