-Transducer Line Gradient -Frequency Range 40 ~ 20,000 Hz -Nominal Impedance 25 ohms -Maximum Output +8.2 dBu (@ 1% THD into 1 kOhm) -Polar Pattern Supercardioid -Sensitivity -20 dB ±2 dB re 1 V/Pa @ 1 kHz -Dynamic Range (Typical) 116 dB (per IEC651) -Signal-to-Noise Ratio 81 dB SPL (A-weighted per IEC651) -Equivalent Noise 8 dBA SPL (A-weighted per IEC651) -Maximum Input Sound Level 124 dB (@ 1 kHz, 1% THD into 1 kOhm load) -Power Re . . .

Read More

-Transducer Line Gradient
-Frequency Range 40 ~ 20,000 Hz
-Nominal Impedance 25 ohms
-Maximum Output +8.2 dBu
(@ 1% THD into 1 kOhm)
-Polar Pattern Supercardioid
-Sensitivity -20 dB ±2 dB re 1 V/Pa @ 1 kHz
-Dynamic Range (Typical) 116 dB (per IEC651)
-Signal-to-Noise Ratio 81 dB SPL (A-weighted per IEC651)
-Equivalent Noise 8 dBA SPL (A-weighted per IEC651)
-Maximum Input Sound Level 124 dB (@ 1 kHz, 1% THD into 1 kOhm load)
-Power Requirements 48 V Phantom Power (44-52 V min 2.5 mA)
-Output Connectors 3-pin XLR, balanced output between Pin 2 (+), Pin 3 (-) and Pin 1 (ground)
