-Frequency Response(Bypass Mode; Analog Processing Chain): Follows standard 50μs or 75μs pre-emphasis curve ±0.10 dB, 2.0 Hz – 15 kHz. Analog left/right output and Digital output can be user configured for flat or pre-emphasized output.
-Samplerate:64 kHz to 512 kHz, depending on processing being performed.
-Noise:Output noise floor will depend upon how much gain the processor is set for (Limit Drive, AGC Drive, Two-Band Drive, and/or Multiband Drive), gating level, equalization, noise reduction, etc. It is primarily governed by the dynamic range of the A/D converter, which has a specified overload-to–noise ratio of 110 dB. The dynamic range of the digital signal processing is 144 dB.
-Total System Distortion (de-emphasized, 100% modulation):<0.01% THD, 20 Hz – 1 kHz, rising to <0.05% at 15 kHz. <0.02% SMPTE IM Distortion.
-Total System Separation:> 55 dB, 20 Hz – 15 kHz; 60 dB typical.
-Polarity (Two-Band and Bypass Modes): (Two-Band and Bypass Modes): Absolute polarity maintained. Positive-going signal on input will result in positive-going signal on output when HD Polarity and FM polarity controls are set to POSITIVE.
