-Frequency Response (Bypass Mode; Analog Processing Chain): Follows standard 50µs or 75µs pre-emphasis curve ±0.10 dB, 2.0 Hz – 15 kHz. Analog left/right output and Digital output can be user configured for flat or pre-emphasized output.
-Sample Rate: 64 kHz to 512 kHz, depending on processing being performed.
-Noise: Output noise floor will depend upon how much gain the processor is set for (Limit Drive, AGC Drive, Two-Band Drive, and/or Multiband Drive), gating level, equalization, noise reduction, etc. It is primarily governed by the dynamic range of the A/D converter, which has a specified overload-to–noise ratio of 110 dB. The dynamic range of the digital signal processing is 144 dB.
-Total System Distortion (de-emphasized, 100% modulation): <0.01% THD, 20 Hz – 1 kHz, rising to <0.05% at 15 kHz. <0.02% SMPTE IM Distortion.
-Total System Separation: > 55 dB, 20 Hz – 15 kHz; 65 dB typical.
-Polarity (Two-Band and Bypass Modes): Absolute polarity maintained. Positive-going signal on input will result in positive-going signal on output when HD Polarity and FM polarity controls are set to POSITIVE.
-Peak Control at HD Output: The peak limiter is oversampled at 256 kHz, yielding a worst- case overshoot of 0.5 dB at the analog output and for all output sample rates. (To achieve this performance at 32 kHz output sample rate, it is necessary to set the 8700i’s HD lowpass filter cutoff frequency to 15 kHz.)
