Four simultaneous live video sources, in any combination of HD Component, SD Component, Y/C or Composite. -Independent frame synchronizers, keying, cropping, Proc Amp and white balance controls on each video input. -Two network sources over Gigabit, with keying, cropping, Proc amp and white balance controls on each input. -Integrated DDR and two graphic sources -Stream HD live, via Adobe Flash or Microsoft Windows Media Push/Pull -Two downst . . .

Read More

Four simultaneous live video sources, in any combination of HD Component, SD Component, Y/C or Composite.
-Independent frame synchronizers, keying, cropping, Proc Amp and white balance controls on each video input.
-Two network sources over Gigabit, with keying, cropping, Proc amp and white balance controls on each input.
-Integrated DDR and two graphic sources
-Stream HD live, via Adobe Flash or Microsoft Windows Media Push/Pull
-Two downstream keyers with independent DVE, and scaling.
-Four independent, mix/effect-style channels supporting multi-source compositions, virtual sets, double-box effects.
-Three configurable sources per channel, each with independent positioning, scaling and cropping, including upstream keyer with DVE and transition controls.
-Up to 5 video layers on the screen at the same time
-Integrated multi-channel audio mixer for internal and external audio sources, output, stream and headphones
-Animation Store Creator
-Integrated TransWarp effects engine on all effects channels supports standard transitions, customizable Animation Store Creator transitions with audio, and overlay effects.
-24 HD live virtual sets, with multiple camera angles, real-time reflections, specular highlights, animated zoom and presets.
-Record in resolutions up to 1080p.
-Source selectable from among Program, Aux, or any single camera input.
-Select from QuickTime, Mpeg-2, Avi and H.264.
-Records up to 20 Hours of 1080i footage, using the internal storage. Longer record times are available by using external media drives.
