-Input Connections 12x XLR balanced 4x XLR & 1/4" TRS combo jack -Mic Preamps Onyx -Input Impedances Channels 1 - 12: 3 kΩ -Channels 13 - 16: 3 kΩ XLR, 30 kΩ 1/4" TRS -Maximum Input Level XLR: +21 dBu 1/4" TRS: +30 dBu Gain XLR: 0 to 60 dB 1/4" TRS: -20 to 40 dB -Phantom Power +48 V -10 mA max per mic, with up to 8 mics -5 mA max per mic, with up to 16 mics -Output Connections 2x XLR balanced (L/R) -Output Impedance 600 Ω . . .

Read More

-Input Connections
12x XLR balanced
4x XLR & 1/4″ TRS combo jack
-Mic Preamps Onyx
-Input Impedances Channels 1 – 12: 3 kΩ
-Channels 13 – 16: 3 kΩ XLR, 30 kΩ 1/4″ TRS
-Maximum Input Level
XLR: +21 dBu
1/4″ TRS: +30 dBu
Gain XLR: 0 to 60 dB
1/4″ TRS: -20 to 40 dB
-Phantom Power +48 V
-10 mA max per mic, with up to 8 mics
-5 mA max per mic, with up to 16 mics
-Output Connections 2x XLR balanced (L/R)
-Output Impedance 600 Ω
-Maximum Output Level +21 dBu
-AUX Sends 1/4″ TRS – supports balanced/unbalanced
-240 Ω balanced, 120 Ω unbalanced
-+21 dBu max output level

Read Less
