-Frequency Response 38 Hz – 20 kHz, (-3 dB)
-SPL 107 dB SPL @ 1m (+4 dBu into balanced input)
-Maximum SPL 113 dB SPL @ 1m (per pair)
-Transducer Low frequency: 8″ (203 mm hyperbolic curved cone woofer)
-High frequency: 1″ (25 mm silk dome tweeter)
-Amplifier Low frequency power: 55 watts, 4 ohm load, 110 watts peak
-High frequency power: 30 watts, 8 ohm load, 60 watts peak
-Type: monolithic IC, class AB with DMOS power stage
-Crossover Crossover type: 24 dB/octave
-Crossover frequency: 3 kHz
-Sensitivity: +4 dBu at 300 Hz for full output
-Input Impedance: 20 kohm balanced bridging; 10 kohm unbalanced
-Equalization Low frequency EQ: +2 dB/+4 dB @ 100 Hz, shelving High frequency EQ: +/- 2 dB @ 3 kHz, shelving
-AC Power 120 VAC, 60 Hz (US)
3-pin IEC 250 VAC, 16 A male connector
-Fuse 115 VAC: T 2 AL / 250 V
230 VAC: T 1 AL / 250 V
-Power Consumption 150 watts with music, loud mix
10 watts quiescent (idle)
-Enclosure .59″ (15 mm) thick MDF with .98″ (25 mm) MDF front panel
-Damping Adiabatic batting
