Microphones
-Female XLR
-Impedance Mic Level: 2k ohms
-Line Level: 50k ohms
-Level Mic Level: -25 dBu nom
-Line Level: +20 dBu max
-Mic/Line Pad Switch -40 dB
-Phantom Power 48 VDC with 6.8k ohm Supply Resistance
Line Input
-1/8″ (3.5mm) Stereo
-Impedance 20k ohms
-Level -10 dBu nom
Headphone Cue In
-1/4″ Mono
-Impedance 20k ohms
-Level -10 dBu nom
Master Output
-Balanced Male XLR
-Impedance 50 ohms
-Level +16 dBu max
-Frequency Response 20 Hz – 20 kHz +/- 1dB
-THD 0.04% THD @ +16 dBu
Line Output
-1/8″ (3.5mm) Stereo
-Impedance 100 ohms
-Level -10 dBu nom
Headphones
-1/4″ Stereo
-Impedance 8 ohms
-Level 1/3 watt per channel
