-FREQUENCY RESPONSE:±0.5dB, 20Hz-15kHz -STEREO SEPARATION:>55dB, 50Hz-15kHz (typically 60-70dB) -NOISE:Better than 70dB below 100% modulation in decoded L/R audio. Individual digital noise components above 54kHz are –70dB or better. -DISTORTION:<0.5%THD in baseband and subcarrier at 95% modulation with PIPP* limiter defeated; <1.5% at any level of modulation with PIPP* limiter engaged. -CROSSTALK (M/S or S/M):Nonlinear crosstalk i . . .

Read More

-FREQUENCY RESPONSE:±0.5dB, 20Hz-15kHz
-STEREO SEPARATION:>55dB, 50Hz-15kHz (typically 60-70dB)
-NOISE:Better than 70dB below 100% modulation in decoded L/R audio. Individual digital noise components above 54kHz are –70dB or better.
-DISTORTION:<0.5%THD in baseband and subcarrier at 95% modulation with PIPP* limiter defeated; <1.5% at any level of modulation with PIPP* limiter engaged.
-CROSSTALK (M/S or S/M):Nonlinear crosstalk is better than –50dB, 50Hz-15kHz. Linear crosstalk (through processing and filters) is better than –40dB.
-PRE-EMPHASIS:75μs or 50μs selected by internal jumpers.

Read Less
