Video Formats 3G HD: 1080/60p, 1080/59.94p, 1080/50p HD: 1080/60i, 1080/59.94i, 1080/50i, 1080/30p, 1080/30PsF, 1080/29.97p, 1080/29.97PsF, 1080/23.98p, 1080/23.98Psf, 1080/25p, 1080/25PsF, 1080/24PsF, 1080/24p, 720/60p, 720/59.94p, 720/50p SD: 525/60, 625/50 -Input x Output 64 × 64 (minimum) to 128 × 128 (maximum) + 4 monitoring outputs (can be expanded in increments of 16 channels) -Cable Equalization 3G/HD-SDI: 100 m (5C-FB or equivalent . . .

Read More

Video Formats 3G HD: 1080/60p, 1080/59.94p, 1080/50p
HD: 1080/60i, 1080/59.94i, 1080/50i, 1080/30p, 1080/30PsF, 1080/29.97p, 1080/29.97PsF, 1080/23.98p, 1080/23.98Psf, 1080/25p, 1080/25PsF, 1080/24PsF, 1080/24p, 720/60p, 720/59.94p, 720/50p
SD: 525/60, 625/50
-Input x Output 64 × 64 (minimum) to 128 × 128 (maximum) + 4 monitoring outputs (can be expanded in increments of 16 channels)
-Cable Equalization 3G/HD-SDI: 100 m (5C-FB or equivalent)
SD-SDI: 200 m (5C-2V or equivalent)
-Temperature / Humidity 32 to 104°F (0 to 40ºC) / 30 to 85% (no condensation)
-Power 2 x 100 to 240 VAC ±10%, 50/60Hz

Read Less
