Channels: 6
-Video Inputs:
4 x HD-SDI
2 x HD-SDI or HDMI (selectable)
-Video Outputs:
6 x HD-SDI (assignable)
2 x HDMI (Multi-View PVW)
-Supported Input Resolutions:
1080i 50/59.94/60
720p 50/59.94/60
-Audio Inputs 4 x XLR (2 stereo pair)
-Audio Outputs 2 x XLR (1 stereo pair)
-Embedded Audio Supported
-Tally Output 1 x DB25
-Control RS-232, RS-422
-Power 12 VDC, 5 A, 48 W
-Power Adapter 100 to 240 VAC . . .
