Response of Audio +/- 0.5 db between 20 and 15,000 Hz, referred to 1,000Hz and 95% modulation
-Total harmonic distortion Less than 1% between 20 and 15,000 Hz, at 95% modulation and nominal power
-Distorsion by Intermodulation Less than 2% at rated power and 85% modulation, with 1,000 and 400 Hz signals in the 1: 1 ratio
-Emission of Non-Essential Harmonics and Radiation Complies with FCC
-Electric Power Consumption 18,750 VA or less, with 0% modulation
-Impedance Input (Audio) 600 Ohms balanced
-Audio Input Level +10 dBm for 100% modulation.
-Adjustable between 0 and +12 dbm
-RF Impedance Impedance 50 Ohms Unbalanced
-Factor Power 0.9 or better
-Modulation Capacity
-120% positive peak modulation: 19.5 KW
-130% positive peak modulation: 18 KW
-150% positive peak modulation: 15 KW
-Efficiency Up to 93% (*)
-Energy Source: Three-phase supply 220/380 VAC, 50/60 Hz
