-Output Power 5,000 watts nominal
-Load Unbalance 50 Ohms Unbalanced
-Response frequency +/- 0.5 dB between 40 Hz and 10 Khz
-Harmonic Distortion less than 1.5% to 90% modulation, measured between 40Hz and 10Khz
-Modulation Capability Better than 140% at peak positive at 100% Nominal power
-Carrier Amplitude Displacement Less than 1%
-Radiation of Harmonic and Spurious Signals Better than 75 dB below the level of the carrier
-Rubid Residual Better than 65 dB
-Frequency Stability +/- 5 Hz or better
-Audio Input Level + 10 dBm nominal for 100% modulation
-Power Supply 220 VAC / 380 VAC with taps of +/- 5% and 10% 1 phase
-Energy Consumption Typical efficiency of 80% for 100% of rated carrier power
-Operating Conditions Ambient temperature – 5ºC and 40ºC Relative humidity between 0% and 90%
-Ability between 0 and 3500mts Snm
