Fifteen logic functions include sustained, toggle, set-reset (flip-flop), dual alternate action or falling/rising edge, along with additional Boolean logic functions.
– The independent pulse stretcher or time delays may be configured from 100ms to 12.7 seconds in 100 millisecond steps, or 10 sec. to 21 minutes and 10 seconds in 10 second steps.
– On/Off LED indicators are provided for relay position status
– A four-position dipswitch is provided for logic function configuration and an eight-position dipswitch is provided for timing configuration.
– Dual power jacks allows for the daisy chaining of units from one wall supply as well as a DC in connection on the terminal block.
– All I/O connections via removable euro-block screw terminals.
