Sensor
Size 25.34 x 14.25 mm (Super-35)
Lens Mount Active Canon EF
Effective Resolution 4608 x 2592
Dynamic Range 15 stops
Shooting Resolutions 4608 x 2592
4096 x 2304 (4K 16:9)
4608 x 1920 (4K 2.4:1)
3840 x 2160 (Ultra HD)
3072 x 2560 (3K Anamorphic)
2048 x 1152 (2K 16:9)
1920 x 1080
Frame Rates 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
Display
Dimensions 5″ diagonal
Screen Type LCD capacitive touchscreen
Resolution 1920 x 1080
Recording
Media Card Slots 2 x CFast 2.0
Recording Formats CinemaDNG Raw (Uncompressed or Lossless 3:1/4:1 Compressed) @ 4608 x 2592, 4096 x 2304, 4608 x 1920, 3072 x 2560, and 2048 x 1152 (film dynamic range)
Apple ProRes @ 3840 x 2160, 1920 x 1080 (film or video dynamic range)
Data Rates 4608 x 2592:
Uncompressed CinemaDNG Raw – 513MB/s
CinemaDNG Raw 3:1 – 180 MB/s
CinemaDNG Raw 4:1 – 135 MB/s
3840 x 2160:
Apple ProRes 444 XQ – 312.5 MB/s
Apple ProRes 444 – 165 MB/s
Apple ProRes 422 HQ – 110 MB/s
Apple ProRes 422 – 73.6 MB/s
Apple ProRes 422 LT – 51 MB/s
Apple ProRes Proxy – 22.4 MB/s
1920 x 1080:
Apple ProRes 444 XQ – 62.5 MB/s
Apple ProRes 444 – 41.25 MB/s
Apple ProRes 422 HQ – 27.5 MB/s
Apple ProRes 422 – 18.4 MB/s
Apple ProRes 422 LT – 12.75 MB/s
Apple ProRes Proxy – 5.6 MB/s
Rates based on 30 frames per second.
Metadata Support Automatic camera data and user entered data such as shot number, filenames, and keywords
Connections
Output 1 x 12G-SDI — 10-bit 4:2:2
Reference 1 x Reference input
Timecode 1 x Timecode input
Analog Audio Inputs 2 x XLR — selected mic/line level and +48 V phantom power
SDI Audio Output 2-channel
Remote Control 2 x LANC on 2.5 mm sub-mini — controls record START/STOP, iris, and focus
USB 1 x USB 2.0 mini type B for software updates
Supported Standards SDI Compliance: SMPTE 292M, SMPTE 424 Level B, Draft SMPTE 2081-1, Draft SMPTE 2082-1
SDI Audio Sampling: 48 kHz and 24-bit
General
Microphone 2 x Built-in cardioid microphones for stereo recording with -10dB pad and low-cut filter
Speaker Integrated mono (enabled in playback when headphones are not used)
Controls Touch screen menus on 5″ screen, push button controls for navigating menus
Mounting Options Integrated rod mounts compatible with 15mm Light Weight Support (LWS) standard
System Requirements Mac OS X 10.9 or newer, Windows 7 (64-bit) or 8 (64-bit)
Note: See Blackmagic website for detailed system requirements and configuration guides.
Power Connectors Inputs:
1 x 4-pin XLR input for external power supply or battery
1 x 12-pin molex connector on rear battery plate
Outputs:
1 x 12V output using 4-pin XLR for powering external accessories such as EVF
1 x 12V regulated output from rear molex 12-way connector
Battery Plate Support Mounting holes for V-mount and Gold Mount battery plates
Operating Temperature 32 to 104°F / 0 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Humidity 0 to 90% RH, non-condensing
Dimensions 8.2 x 7.6 x 5.8″ / 21 x 19.3 x 14.7 cm
Weight 5 lb / 2.3 kg
Packaging Info
Package Weight 8.15 lb
Box Dimensions (LxWxH) 12.9 x 10.0 x 7.9″
