COBRANET INPUT/OUTPUT
Type 100BaseT Ethernet
Connector RJ-45
Precision 16, 20 or 24bit PCM
Sample Rate 48kHz
Latency 1.33, 2.67 or 5.33ms
Control Protocol SNMP

ANALOG OUTPUT
Type Balanced
Connector 3.81mm Terminal block
Output Level -10 to +24dBu in 1dBu steps
Dynamic Range [1] >105dB
THD+N [2] <0.0015%
Sample Rate 48kHz
Frequency Response 20Hz to 20kHz +0.1/-0.30dB

LATENCY (48 kHz CobraNet) 5.33ms CN latency 2.67ms CN latency 1.33ms CN latency
CobraNet input to analog output 6.93ms 4.33ms 2.99ms

REGULATORY
FCC Part 48 Class A (US)
CE Mark (EN55022 Class A EN55024)
RoHS Compliant

GENERAL
Dimensions 1 U, 19”(482mm) W x 8”(203mm) L x 1.75”(44mm) H
Weight 7 lb (3.2kg) max
Operating Temperature 0C to 60C
Power Requirements 100-240VAC, 47-63Hz, 25W max.
