Total # Of Inputs 24
-Mic/Line Inputs 3-pin XLR Balanced Microphone x16
-1/4″ Phone Balanced Line x24
-Stereo Line Inputs ST1 – ST4 1/4″ Phone L/R Stereo
-In-Line Inputs/Returns No
-AUX Sends 1/4″ TRS Phone x4
-AUX Returns 1/4″ TRS Phone x4
-Inserts 1/4 TRS Phone x18 (Mono chs and Main Stereo Out)
-BUS (Group) Outputs No
-2 Trk Master I/O Main Output: Balanced 3-pin XLR
-ALT I/O USB Connector 1/4″ Phone Mono Out
-Monitor Outputs RCA Stereo Phono – ALT Out
-RCA Stereo Phono – REC Out
-EQ Section 3-Band with Mid Sweep On all Mono Channels
-2-Band On Stereo Channels
-Solo/Mute Mute and PFL Solo
-Channel Level Control 100mm Fader
-Trim/Gain Control Rotary Control
-Phantom Power +48V Switched Globally
-Metering 12 Segment Peak LEDs
-Frequency Response 20Hz to 20kHz
-Dynamic Range Not Specified By Manufacturer
-Signal-to-Noise Ratio -88dBu
-Total Harmonic Distortion (THD) 0.004%
-Power Supply 100-240V 47-63Hz 40W Max
