-Frequency Response (pre-emphasis defeated): ±1dB, 10Hz-8.7kHz (Euro MW) -Distortion: Less than 0.2% THD, 10Hz cutoff with Peak Limiter OFF; less than 1% THD, 200Hz cutoff with Peak Limiter ON -Noise: Better than 75dB below full carrier modulation -Fixed Pre-Emphasis: Appropriate to the service and the cutoff frequency -Input: Active-balanced, bridging; accepts nominal program line levels between -15dBu and +15dBu. -Output: Active-balanced, . . .

Read More

-Frequency Response (pre-emphasis defeated): ±1dB, 10Hz-8.7kHz (Euro MW)
-Distortion: Less than 0.2% THD, 10Hz cutoff with Peak Limiter OFF; less than 1% THD, 200Hz cutoff with Peak Limiter ON
-Noise: Better than 75dB below full carrier modulation
-Fixed Pre-Emphasis: Appropriate to the service and the cutoff frequency
-Input: Active-balanced, bridging; accepts nominal program line levels between -15dBu and +15dBu.
-Output: Active-balanced, 600-ohm resistive source; delivers 0dBm to +15dBm into 600 ohms.
-Output Asymmetry: Positive peak amplitude is continuously variable between +100% and +130% of the negative peak value
-Power Requirements: 210-260 VAC; 50/60Hz; 20W

Read Less
