Analog Video Inputs Composite Video: 1 Vpp, 75 Ω internally terminated -Analog Video Outputs Composite Video: 1 Vpp, must be terminated -Audio Bandwidth: 20 to 20 kHz < ±3 dB -S/N Ratio: >50 dB -THD: <0.15% -Time Code In SMPTE, 0.5 to 5 Vpp, BNC -Video In/Out Digital: IEEE-1394, 400 Mbps maximum, 6-pin -Triggers GPI: 1.65 V threshold, 100 kΩ input, contact closure . . .

Read More

Analog Video Inputs Composite Video: 1 Vpp, 75 Ω internally terminated
-Analog Video Outputs Composite Video: 1 Vpp, must be terminated
-Audio Bandwidth: 20 to 20 kHz < ±3 dB
-S/N Ratio: >50 dB
-THD: <0.15%
-Time Code In SMPTE, 0.5 to 5 Vpp, BNC
-Video In/Out Digital: IEEE-1394, 400 Mbps maximum, 6-pin
-Triggers GPI: 1.65 V threshold, 100 kΩ input, contact closure
