COBRANET INPUT/OUTPUT
Type 100BaseT Ethernet
Connector RJ-45
Precision 16, 20 or 24bit PCM
Sample Rate 48kHz
Latency 1.33, 2.67 or 5.33ms
Control Protocol SNMP

MICROPHONE/LINE INPUT
Type Balanced
Connector 3.81mm Terminal block
Input Level -10 to +24dBu in 1dB increments
Input Impedance 10K Ohms
Dynamic Range [1] >105dB
THD+N [2] <0.0015% (record or play)
A/D converter 24bit Over sampling
Sample Rate 48 kHz
Frequency Response 20Hz to 20kHz +/-0.25dB

ANALOG OUTPUT
Type Balanced
Connector 3.81mm Terminal block
Output Level -10 to +24dBu in 1dBu steps
Dynamic Range [1] >105dB
THD+N [2] <0.0015%
Sample Rate 48kHz
Frequency Response 20Hz to 20kHz +0.1/-0.30dB
