Effective Picture Elements 1920 (H) x 1080 (V)
-Gain -3, 0, 3, 6, 9, 12, 18 dB, AGC
-Horizontal Resolution 1,000 TV lines or more (1920 x 1080i mode)
-Imaging Device 3-chip 1/2-inch type Exmor Full HD CMOS
-Minimum Illumination 0.02 lx (typical) (1920×1080/59.94i mode, F1.9, +18 dB gain, with 64-frame accumulation, Gamma on, 50% video level)-
-0.12 lx (typical) (1920×1080/59.94i mode, F1.9, +18 dB gain, with 64-frame accumulation, Gamma off, 100% video level)
-Optical System F1.6 prism system
-S/N Ratio 60 dB (Y) (typical)
-Sensitivity (2000 lx, 89.9% reflectance) F11 (typical) (1920 x 1080/59.94i mode)
-Shutter Speed (Time) 1/32 sec to 1/2,000 sec
-Slow & Quick Motion Function 720p: 1 – 60 frames (1 – 50 frames for PAL mode, UDF)–
1080p: 1 – 30 frames (1 – 25 frames for PAL mode, UDF)
-Slow Shutter 2, 3, 4, 5, 6, 7, 8, 16, 32, and 64-frame accumulation
-White Balance Preset (3,200 K), Memory A, Memory B/ATW
-Battery Operating Time Approx. 3.6 hrs with BP-U90 battery (while recording, with viewfinder, I/O Select Off)
-Built-in Microphone Omni-directional stereo electret condenser microphone.-
-Operating Temperature 32°F to 104°F (0°C to 40°C)
-Power Consumption Approx. 20 W (while recording, with viewfinder, IO Select Off)
-Power Requirements DC IN: 12 V
-Battery: 11 V to 17 V
-Audio Input XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable – LINE: +4 dBu – MIC: -70 dBu to -30 dBu
-Audio Output RCA pin jack (CH-1, CH-2)
-Composite Output VIDEO OUT: BNC type
-DC Input DC jack (1)
-DC Output No
-EXT 50-pin No
-Genlock Input BNC type (1), switchable with VIDEO OUT connector 1.0Vp-p, 75Ω
-HDMI Output HDMI connector – Type A (1)
-Headphone Output Stereo mini-jack (1) -18 dBu 16 Ω
-Lens Remote 8-pin round (1)
-Remote 8-pin
-SDI Output BNC (x2), HD-SDI/SD-SDI selectable
-SMPTE292M/259M
-Timecode Input BNC (1), switchable to TC OUT connector SMPTE 12M-2-2008 standard 0.5V-1.8Vp-p, 10kΩ)
-Timecode Output BNC (1), switchable to TC IN connector SMPTE 12M-2-2008 standard 1.0Vp-p, 10kΩ)
-USB Mass Storage: USB 2.0 mini-B (1) Host: Type-A USB2.0(1)
-VF Yes
-Video Output BNC (1), HD-Y / Composite switchable, 1.0 Vp-p, 75Ω
-switchable to GENLOCK IN connector
-i.LINK IEEE 1394, 4-pin connector (1) HDV (HDV 1080i) input/output DV input/output, S400
-Filter Diameter M77 mm, pitch 0.75mm
-Focal Length 5.8-81.2mm (35mm Equiv: f=31.4mm-439mm)
-Iris F1.9-F16 and Close
-Lens Mount 1/2-type EX mount
-Zoom System Optical 14x
